Description
| CPU Socket Type | LGA 1700 |
|---|---|
| Core Name | Alder Lake |
| # of Cores | 10-Core (6P+4E) |
| # of Threads | 16-Threads |
| Operating Frequency | P-core Base Frequency: 3.7 GHz E-core Base Frequency: 2.8 GHz |
| Max Turbo Frequency | Single P-core Turbo Frequency: Up to 4.9 GHz Single E-core Turbo Frequency: Up to 3.6 GHz |
| L2 Cache | 9.5MB |
| L3 Cache | 20MB |
| Manufacturing Tech | Intel 7 |
| 64-Bit Support | Yes |
| Hyper-Threading Support | Yes |
| Memory Types | DDR4 3200 / DDR5 4800 |
| Memory Channel | 2 |
| Max Memory Size | 128 GB |
| ECC Memory | Supported |
| Max Memory Bandwidth | 76.8 GB/s |
| Virtualization Technology Support | Yes |
| Integrated Graphics | Intel UHD Graphics 770 |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.45 GHz |
| PCI Express Revision | 5.0 / 4.0 / 3.0 |
| Max Number of PCI Express Lanes | Up to 1×16+4, 2×8+4 expert zone |
| Thermal Design Power | Processor Base Power: 125W Maximum Turbo Power: 150W |
| Cooling Device | Cooling device not included – Processor Only – TRAY |
| Operating System Supported | Windows 11 |
